3 Bar MAP Sensor Boost Pressure Sensor Replacement for Buick Encore Chevrolet Cruze Sonic Trax 1.4T LUV 55568175 0281006076 0281002845
5.0 (60 items)
Limited Time Sale$15.60 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 217701307 | Release Date | 2026/04/19 | List Price | $10.40 | Model Number | 217701307 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Pin 1 = Signal ground, Pin 2 = NTC, Pin 3 = +5V, Pin 4 = Signal output Pressure Range: 20-300 KPA 400-4650 MV O-ring size : 12.5 mm Pin 1 = Signal ground, Pin 2 = NTC, Pin 3 = +5V, Pin 4 = Signal output This T-MAP is an excellent sensor for forced induction applications such as turbocharged and supercharged vehicles. 3 bar Map sensors are not intended for naturally aspirated applications. Compatible with Porsche 997.1 Turbo 2007-2009, GT2 2007-2009, GT2 RS 2011 (Plug and Play Sensor) With the factory sensors limited to around 22 psi, the 3-Bar MAP Sensor Kit will allow accurate measuring up to 30psi. GM Stage 1 MAP Sensor for LNF 2.0 turbo Cobalt SS, HHR SS, Sky Redline, and Solstice GXP
- 3 Bar MAP Sensor with IAT (4-Pin Pressure Sensor T-MAP) Manifold Absolute Pressure Sensor Turbocharger Boost Sensor
- Replaces Part Number: 0281006076, 55568175, 0281006077, 0281002845, 55206797, 93171176, 0281002437
- Pressure Range: 20-300 KPA, 400-4650 mV
- GM Stage 1 MAP Sensor for LNF 2.0 turbo Cobalt SS, HHR SS, Sky Redline, and Solstice GXP
- Direct Replacement for 2013+ Buick Encore Chevrolet Cruze Sonic Trax 1.4T LUV Engine (Pressure sensor located on the intercooler outlet pipe)
| Model | 0281006077 |
|---|---|
| Brand Name | NATAFOX |
| Style Name | Modern |
| Item Weight | 44 Grams |
| Output Type | Digital |
| Manufacturer | A-Redline Auto Parts |
| Material Type | Plastic |
| Mounting Type | Flange Mount |
| Measuring Range | 20-300 kPA |
| Included Components | 3 Bar MAP Sensor (Turbocharger Boost Sensor) |
| Measurement Accuracy | ±1% |
| Warranty Description | Manufacturer Warranty for 180 Days from Date of Purchase |
| Maximum Supply Voltage | 5 Volts (DC) |
| Specific Uses For Product | Pressure Sensor,Temperature Sensor |
