waveshare ESP32-C6 1.9inch Touch Display Development Board,170×320 Pixels 262K Color LCD Screen Support 2.4GHz WiFi and Bluetooth BLE 5 Supports 90°Hardware Rotation

ESP32-C6 1.9inch Touch Display Development Board, 170×320 Pixels, 262K Color, 160MHz Running Frequency RISC-V Single-Core Processor, WiFi 6 & Bluetooth, Supports 90° Hardware Rotation, ESP32 With Display Features This product adopts ESP32-C6FH8 chip with 2.4GHz Wi-Fi 6 and Bluetooth BLE 5 support, integrates 8MB Flash. Onboard 1.9inch LCD display which can smoothly run GUI programs such as LVGL. Onboard QMI8658 6-axis IMU, TF card slot, Lithium battery header, etc. Compatible with Pico header, offering strong compatibility and expandability. It is suitable for the quick development of the HMI and other ESP32-C6 applications. Equipped with a high-performance 32-bit RISC-V processor with clock speed up to 160 MHz Supports 2.4GHz Wi-Fi 6 (802.11 b/g/n) and Bluetooth 5 (LE), with an onboard antenna Built-in 512KB HP SRAM, 16KB LP SRAM, and 320KB ROM, integrates 8MB Flash Onboard 1.9inch LCD display, 170 × 320 resolution, 262K color, delivering clear and vivid color image display Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gestures, counting steps, etc. Onboard USB Type-C port for power supply, program downloading, and debugging, more convenient for development use Onboard 3.7V MX1.25 Lithium battery recharge/discharge header Onboard TF card slot for external TF card storage of pictures or files Compatible with Pico header, onboard multiple peripheral interfaces, offering strong compatibility and expandability LCD Parameters DISPLAY PANEL---LCD DISPLAY SIZE---1.9 inch RESOLUTION---170×320 DISPLAY COLORS---262K BRIGHTNESS---500 cd/㎡ CONTRAST RATIO---900:1 COMMUNICATION INTERFACE---SPI DRIVER IC---ST7789V2 TOUCH IC---CST816 (Touch Version Only) Package Content ESP32-C6-Touch-LCD-1.9 x1

• ESP32-C6 1.9inch Touch LCD Display Development Board，170 × 320, Embedded with ST7789V2 Display Driver, Supports 90° Hardware Rotation
• Supports ESP-IDF, Arduino IDE，Comprehensive SDK, Dev Resources, Tutorials To Help You Easily Get Started
• Wi-Fi 6 And BLE 5 Support，ESP32-C6 integrates 2.4 GHz Wi-Fi 6 (802.11 ax/b/g/n) with 40 MHz bandwidth support. Its Bluetooth Low Energy subsystem supports Bluetooth 5 (LE) and Bluetooth Mesh
• Interface Definition，Compatible With Pico Header, Can Be Used With Some Raspberry Pi Pico HATs, Offering Strong Compatibility And Expandability
• Brightness:500 cd/㎡,Contrast Ratio:900:1
